    HD ISDB T TV Set Top Box Compatible HD TV Decoder Receiver HDMI CVBS Output

    Ask Lasest Price
    Brand Name : Colable
    Model Number : COL601M
    Price : Negotiation
    Payment Terms : T/T (Wire Transfer), Western Union etc
    Supply Ability : 10000sets per Month
    Delivery Time : 2-5 working days for sample
    • Product Details
    • Company Profile

    HD ISDB T TV Set Top Box Compatible HD TV Decoder Receiver HDMI CVBS Output

    Model: COL601M HD TV Decoder Receiver

    HD ISDB-T Set Top Box for South American Market


    Feature


    • Supports all ISDB-T broadcast (1, 3, 13 segment), MPEG-2/MPEG-4 AVC/H.264 HD/SD Video , DiVX compliant
    • Compatible with 576i/576p/720p/1080i/1080p video formats
    • Auto and manually scan all available TV and radio channels
    • Aspect ratio 16:9 and 4:3, 1000 channels memory, parental control
    • HDMI, YPbPr, coaxial outputEPG (Electronic Program Guide) with now & next and 7 days events ready
    • Teletext/ Bit Map subtitle, compliant with ETS1
    • Supported 7-Day EPG function, VBI Teletext
    • Support 6MHz software setting Auto/Manual Program search, Multi-language
    • USB 2.0 for PVR, Software upgrade, Multimeida Playback
    • Demodulation: QPSK / 16QAM / 64QAM/QPSK or DQPSK;OFDM Reception Channel:: 13CH-62CH
    • Digital reception covers VHF & UHF band

    Specification


    Tuner(MXL)IF input frequency7-68 Ch (470mHz~806mHz)
    Bandwith6MHz
    Input level-90 ～ -5dBm
    Input impedance50 Ω
    Channel DecodingWave formCOFDM
    DemodulationQPSK,16QAM,64QAM, QPSK or DQPSK
    FEC1/ 2, 2/3, 3/4, 5/6, 7/8 Automatic
    Mode2K, 4K, 8K
    Guard1/4, 1/8, 1/16, 1/32
    DemultiplexerStandardISO/IEC13818-1, MPEG-4HE AAC
    Input Max. TS23.420Mbps

    Video Decoding


    		Video resolution:1080i/720p/576p/576i(PAL),1080p720p/480p/480i(NTSC)
    StandardISO/IEC 13818-2, MPEG-2 MP@ML, H.264
    Aspect ratio4:3, 16:9
    Video formatPAL / NTSC/ AUTO
    Audio DecodingStandardISO/IEC 13818-3
    DecodingMPEG-1 Layer I and II, MPEG-2, MPEG-4 AAC, MP3
    Processor and MemoryCPUMstar 7816
    Frequency216 MHz
    DDR RAM512MB
    Flash Memory32MB
    Video de-emphasisCCIR REC.405-1, 1080i
    AV OutputVideo bandwidth5.5 MHz
    Video output impedance75 Ω
    Video output level1.0Vp-p
    Audio outputCoaxial, L/R, HDMI
    Audio output frequency20Hz ~ 20KHz
    Audio output impedanceLow
    Audio output level:A 1.0Vrms ± 2dB into 10K
    Hardware InterfaceIndicatorsPower, signal lock
    IR Receive38KHz
    AV outputYUV, HDMI, Composite Video
    RF InputEC-type IEC169-2 Female
    Loop Through OutIEC-type IEC169-24 Male
    USBUSB1.1- USB2.0
    Power input Spec90—260V AC 8W max



    Digital IPTV, CATV+IPTV System









    Certificates





    Colable Electronics co.,ltd

    Specialize in Digital TV broadcasting equipment for more than 10 years, and experienced in Digital Cable/Satellite/ Terrestrial tv broadcasting solution and system, If you have any questions and ideas, please no hesitate to contact us!

    • Our experience: Standing in digital system solution more than 10 years, with reliable Team.
    • Our products: FTA & Descrambler Satellite Decoder, Encoder, Multiplexer, Scrambler, Modulator, Set Top Box etc.
    • Payment: Wire Transfer (T/T), Western Union, Paypal, Trade Assurance etc.
    • Delivery Date: 2-5 working days
    • Our services: Life-long Technical support, remote assistance
    • Warranty: 1 year for headend & STB

    Please feel free to ask if you have any questions. Welcome !!!
